Schneider Electric / Square D Model 5 - Breaker MCC Bucket - 100 A, 480 V, 9" Height, 3 P | AmpState

Engineered for demanding industrial motor control applications, the Schneider Electric / Square D Model 5 Breaker MCC Bucket delivers a precise, ready-to-install replacement for Model 5 MCC systems. Rated at 100 A, 480 V, and configured for 3-Pole operation, this bucket is designed to drop into existing Model 5 assemblies and keep critical motor loads running smoothly. Whether you’re refreshing aging equipment or stocking up for planned maintenance, this MCC bucket provides an exact-fit solution that minimizes downtime and preserves system performance.

• Exact fit for Schneider Electric / Square D Model 5 MCCs – Maintains the original mounting pattern, electrical interfaces, and footprint so installation is straightforward and reliable.
• 100 A at 480 V, 3-Pole – Suits medium-sized motor loads common in conveyors, pumps, fans, and processing equipment without overloading the distribution path.
• 9" height – Consistent with the standard Model 5 MCC bucket envelope, ensuring seamless compatibility with existing enclosures and bus connections.
• OEM replacement for retrofit – A purpose-built alternative to generic buckets, offering tested compatibility and proven performance in both new builds and retrofits.
• Reliable Schneider Electric / Square D lineage – Backed by the reputation and engineering heritage of a globally trusted control system brand, delivering predictable behavior in mission-critical environments.
• AmpState global delivery – Access to a ready supply of MCC components with worldwide shipping, so downtime can be minimized regardless of location.

Ideal use cases

• Maintenance planning for industrial facilities with Model 5 motor control centers.
• Retrofit projects that refresh aging MCC infrastructure without redesigning the control architecture.
• Spare part strategy for critical lines to reduce downtime in production environments.
• Field service and repair scenarios where a direct, spring-loaded replacement ensures quick restoration of motor service.

Practical considerations and tips

• Verify that your system is a Schneider Electric / Square D Model 5 MCC before ordering to ensure seamless compatibility.
• Power down the controller and lockout/tagout the line before attempting any replacement tasks; follow your site’s safety procedures.
• Have the corresponding OEM-grade wiring harnesses and mounting hardware available, as the bucket is designed to integrate with existing interfaces.
• After installation, perform a controlled power-up and basic functional test to confirm proper trip/feeder operation and motor coordination.

Why this matters – In industrial environments, matching the exact electrical characteristics and physical footprint of the original Model 5 MCC bucket is critical. This replacement preserves the original trip curves, fault protection behavior, and connection layouts, which translates to fewer configuration surprises, faster inventories, and reduced commissioning time compared with non-OEM alternatives.

Specification snapshot

• Brand: Schneider Electric / Square D
• Model: Square D Model 5
• Configuration: Breaker MCC Bucket
• Rating: 100 A, 480 V, 3-Pole
• Height: 9"
• Purpose: Direct OEM replacement for Model 5 MCC systems
