GE TEYL3090B - 90 A, 480 V, 3-Pole Bolt-On Circuit Breaker | AmpState

The GE TEYL3090B is a 90A, 480V, 3-pole bolt-on molded case circuit breaker designed to deliver dependable branch circuit overcurrent and short-circuit protection in panelboards and load centers. Built for enduring performance, it provides precise protection characteristics in residential, commercial, and light industrial environments.

What sets the TEYL3090B apart

• Secure bolt-on mounting creates a rigid, vibration-resistant bus connection, reducing movement that can loosen connections and affect protection reliability.
• Thermal-magnetic trip unit delivers stable, repeatable protection by combining a thermal element for overload detection with a magnetic element for short-circuit response.
• OEM-compatible design engineered to work with matching GE OEM loadcenters and panelboards for seamless integration and warranty alignment.
• Three-pole configuration (3P) is ideal for three-phase systems common in commercial and light industrial setups, providing balanced protection across all phases.
• Versatile application suited for residential, commercial, and light industrial distribution networks that demand reliable 480V protection.

Technical snapshot

• Manufacturer: GE
• Part Number: TEYL3090B
• Type: Thermal-magnetic molded case circuit breaker
• Amperage Rating: 90A
• Voltage Rating: 480V
• Number of Poles: 3
• Mounting Style: Bolt-on
• Application: Branch circuit overcurrent and short-circuit protection

Ideal use cases

• Commercial electrical panels and distribution boards needing reliable 3-phase protection at 480V.
• Residential-adjacent and light industrial installations where durable bolt-on protection is preferred for vibration-prone environments.
• Retrofits or new builds that require OEM-compatible breakers to maintain panel performance and warranty coverage.

Practical guidance for deployment

• Match the TEYL3090B with the corresponding GE OEM load centers to ensure optimal fit and protection coordination.
• Verify conductor ampacity and upstream protection to ensure the 90A rating aligns with system design and safety requirements.
• Utilize the bolt-on mounting to maximize mechanical stability in panels that experience vibration or movement during operation.
