GE TED136090WL is a 90A, 600V, 3-pole molded case circuit breaker designed to deliver dependable branch circuit overcurrent and short-circuit protection in panelboards and load centers. With a focus on efficient space use and consistent protection, this unit is a practical, reliable choice for a range of electrical installations—from compact residential setups to light commercial and industrial applications.

• Compact molded case design: Optimizes panel space, enabling smoother, cleaner panel layouts and easier expansion.
• Thermal-magnetic trip unit: Provides stable, repeatable protection performance. The thermal element handles typical overloads, while the magnetic mechanism responds instantly to high-current faults for rapid clearance.
• OEM-compatible: Built to integrate with matching GE OEM load centers and panelboards, simplifying substitution, retrofits, or upgrades in existing systems.
• Three-pole construction: Suitable for three-phase systems, delivering coordinated protection across all phases.
• Versatile applications: Ideal for residential, commercial, and light industrial environments where reliable branch-circuit protection is essential.

Key use cases include protecting feeder and branch circuits in commercial panelboards, upgrading protection in light industrial electrical systems, and providing a dependable, code-aligned protection point in new installations. The 90A, 600V rating suits moderate-load circuits and distribution feeders, helping you maintain system safety while conserving panel space.

Why choose the GE TED136090WL

When reliability matters, this GE molded case breaker combines space efficiency with a proven thermal-magnetic protection strategy. Its design aligns with standard panelboard architectures, enabling straightforward integration into existing setups and ensuring consistent trip performance across varying load conditions. If you’re coordinating multiple breakers in a panel, this unit’s three-pole configuration helps maintain balanced protection across all phases, reducing the risk of nuisance trips and improving overall system stability.

Technical specifications

• Manufacturer: GE
• Part Number: TED136090WL
• Type: Thermal-magnetic molded case circuit breaker
• Amperage Rating: 90A
• Voltage Rating: 600V
• Number of Poles: 3
• Application: Branch circuit overcurrent and short-circuit protection
