GE TED136090 - 90 A, 600 V, 3-Pole Circuit Breaker | AmpState

The GE TED136090 is a 90 A, 600 V, 3-pole molded case circuit breaker designed to deliver dependable branch circuit overcurrent and short-circuit protection within panelboards and load centers. Its compact form fits tight electrical spaces while maintaining robust protection for three‑phase systems, making it a reliable choice for commercial and light industrial applications as well as residential setups with three‑phase requirements.

Why this 3-pole MCCB stands out

• Thermal-magnetic trip unit delivers stable, repeatable protection performance by responding precisely to overloads and short circuits, reducing nuisance trips while safeguarding wiring and equipment.
• Compact molded case design optimizes panel space, letting you fit more protection without sacrificing safety or reliability.
• 3-pole configuration is ideal for 3-phase distribution, feeders, and equipment in commercial and light industrial environments.
• 600 V rating broadens compatibility with mid- to high-voltage panel schemes and control circuits.
• OEM-load center compatibility ensures smooth integration with GE and compatible OEM panelboards, reducing installation complexity and part mismatches.

Ideal use cases

• New installations and upgrade projects in panelboards and load centers that serve commercial spaces, schools, retail, and light industrial facilities.
• Replacement protection in existing GE TED or compatible OEM panels to restore reliable branch-circuit safety.
• Three-phase feeders and distribution circuits where a precise 90 A protection point is required for safe operation.

How it protects your electrical system

When current exceeds safe levels due to overload or a short, the thermal-magnetic mechanism opens the circuit, interrupting power before damage can occur. This predictable trip behavior helps prevent equipment failure, minimizes downtime, and supports safer maintenance and operation across distributed systems.

Installation and compatibility notes

• Ensure you are using the exact part number TED136090 for a seamless fit in GE and compatible OEM load centers.
• Designed for panelboard environments where space efficiency and reliable protection are essential; verify the breaker fits your enclosure and wiring scheme before installation.
• Suitable for residential, commercial, and light industrial applications that require dependable three‑phase protection with straightforward maintenance.

Technical specifications at a glance

• Manufacturer: GE
• Part Number: TED136090
• Type: Thermal-magnetic molded case circuit breaker
• Amperage Rating: 90 A
• Voltage Rating: 600 V
• Number of Poles: 3
• Application: Branch circuit overcurrent and short-circuit protection

Available through AmpState, the GE TED136090 combines precise protection with practical design to keep panels organized, compliant, and performing at peak efficiency. If your project calls for trusted GE protection in a compact, three‑pole package, this breaker is engineered to deliver clear, dependable results.
