GE TED134090WL - 90 A, 480 V, 3-Pole Circuit Breaker | AmpState

Meet the GE TED134090WL — a compact, 90A, 480V, 3-pole molded case circuit breaker built to safeguard your panelboards and load centers. Designed for reliable branch circuit overcurrent and short-circuit protection, this GE unit fits seamlessly into existing systems and delivers dependable performance in demanding environments.

Key advantages that set this breaker apart

• Compact molded case design maximizes panel space, allowing cleaner installs and easier field upgrades.
• Thermal-magnetic trip unit provides stable, repeatable protection across varying loads and temperatures, helping prevent nuisance trips while ensuring fast fault clearance when it matters most.
• Three-pole configuration delivers balanced protection for three-phase systems, making it ideal for 480V commercial and light industrial applications.
• OEM-compatible for GE panelboards and load centers, simplifying replacement and maintenance with a direct-fit option.
• Versatile application range suitable for residential, commercial, and light industrial environments where reliable branch circuit protection is essential.

Technical snapshot

• Manufacturer: GE
• Part Number: TED134090WL
• Type: Thermal-magnetic molded case circuit breaker
• Amperage Rating: 90A
• Voltage Rating: 480V
• Number of Poles: 3
• Application: Branch circuit overcurrent and short-circuit protection

Ideal use cases

Use the GE TED134090WL when you need reliable protection for three-phase 480V systems in panelboards and load centers. It’s a practical choice for refurbishing existing GE installations, stocking spare parts for service fleets, or expanding capacity in commercial spaces, manufacturing lines, or light industrial facilities. Its 90A rating makes it well-suited for mid-range protection needs without compromising on safety or performance.

Installation and compatibility tips

• Ensure the panelboard or load center is compatible with GE TED series molded case breakers and supports 3-pole configurations at 480V.
• Match the trip characteristics to your system’s protection coordination plan to minimize disruption from nuisance trips while still catching faults quickly.
• Follow all local electrical codes and manufacturer installation guidelines during replacement or upgrade projects.
• Keep spare parts handy for maintenance-ready panel systems to reduce downtime during service windows.

Why this matters for your system

Choosing the GE TED134090WL means locking in a dependable, space-efficient solution that integrates smoothly with existing GE panelboards and load centers. The thermal-magnetic trip unit delivers predictable performance across a range of operating conditions, helping facilities maintain uptime and protect critical circuits without overcomplicating maintenance. If you’re upgrading, repairing, or expanding a 480V three-phase setup, this 90A molded case breaker offers a practical balance of protection, compatibility, and panel efficiency.
