GE TED124090WL - 90 A, 480 V, 2-Pole Circuit Breaker | AmpState

GE TED124090WL is a 90A, 480V, 2-pole molded case circuit breaker designed to deliver reliable branch-circuit overcurrent and short-circuit protection in panelboards and load centers. Built to fit GE OEM panels and compatible with other panel systems that specify this model, it combines compact sizing with robust protection for demanding electrical environments.

• Space-conscious design: The compact molded case form factor helps maximize panel space, making it easier to fit into tight electrical enclosures without sacrificing protection performance.
• Thermal-magnetic trip unit: A dual-action protection strategy where the thermal element handles overloads and the magnetic element responds to short circuits. This yields stable, repeatable protection across varying temperatures and load conditions, with fast, predictable tripping when faults occur.
• OEM-compatible for seamless integration: Specifically engineered to drop into GE OEM load centers and compatible panelboards, ensuring proper mounting, wiring terminations, and coordinated protection with existing devices.
• Versatile for multiple settings: Suitable for residential, commercial, and light industrial applications, including 480V distribution scenarios where reliable two-pole protection is essential.
• Two-pole protection, synchronized disengagement: The 2-pole design ensures both hot conductors disconnect simultaneously, which is critical for maintaining safe, code-compliant operation on 480V circuits and equipment like motors and transformers.

Technical specifications at a glance

• Manufacturer: GE
• Part number: TED124090WL
• Type: Thermal-magnetic molded case circuit breaker
• Amperage rating: 90 A
• Voltage rating: 480 V
• Number of poles: 2
• Application: Branch circuit overcurrent and short-circuit protection

Ideal use cases

• Feeder protection in commercial and light industrial 480V distribution panels
• Safety-enhanced protection for electrical rooms, service panels, and load centers
• Motor and equipment protection where reliable trip performance and panel-space efficiency matter

Practical installation tips

• Verify panelboard compatibility: choose TED-series breakers when upgrading GE OEM panels to maintain correct trip characteristics and fit.
• Plan for fast fault response: rely on the thermal-magnetic trip to handle normal overloads while providing swift magnetic trips for short circuits.
• Follow proper wiring practices: ensure correct terminal sizing and secure terminations to maintain long-term reliability in 480V environments.

When you’re configuring 480V distribution in a commercial or light industrial setting, the GE TED124090WL delivers dependable, well-coordinated protection in a compact form factor. This is a trusted choice for engineers and electricians seeking a precise, compatible solution for GE OEM panelboards and compatible enclosures.
