GE TED113090WL - 90 A, 277 V, 1-Pole Circuit Breaker | AmpState

GE TED113090WL is a 90A, 277V, 1-pole molded case circuit breaker engineered to deliver dependable branch circuit overcurrent and short-circuit protection in panelboards and load centers. Built for consistent performance in demanding environments, this breaker helps keep critical circuits safe without compromising panel space.

Compact, space-efficient protection

The molded case design is optimized to maximize panel space, making it easier to fit within compact electrical rooms or crowded load centers while still delivering reliable protection for essential circuits.

Thermal-magnetic trip for stable protection

Equipped with a thermal-magnetic trip unit, the TED113090WL delivers stable, repeatable protection. The thermal element responds to gradual overcurrent conditions, while the magnetic component provides instantaneous action on short-circuit events, helping minimize equipment damage and downtime.

Designed for OEM compatibility

This breaker is specifically compatible with matching OEM load centers and panelboards, ensuring proper fit, electrical performance, and coordinated protection with your existing system.

Technical snapshot

• Amperage rating: 90 A
• Voltage rating: 277 V
• Number of poles: 1
• Type: Thermal-magnetic molded case circuit breaker
• Application: Branch circuit overcurrent and short-circuit protection

Ideal applications

Suitable for residential projects, commercial installations, and light industrial environments that run on 277V power, where reliable protection for critical branch circuits in panelboards and load centers is essential.

Practical use and maintenance tips

When selecting a replacement or upgrading an existing panel, verify compatibility with your OEM panelboard and confirm the circuit’s requirements. Ensure secure terminations and follow standard electrical safety practices during installation and routine inspections to maintain optimal protection performance.
