Eaton PINFD - Breaker Plug-In Enclosure for 100A Busway | AmpState

The Eaton PINFD Breaker Plug-In Enclosure is purpose-built to extend molded-case protection directly from a 100A busway. Designed for ED, EHD, and FDB breakers in the 15–100A range, PINFD provides a compact, plug-in solution that taps protection off the Eaton 100A busway with a clean, integrated interface. Ideal for scalable distribution, it lets you add protection where you need it without overhauling your existing busway layout.

• Plug-in compatibility with Eaton 100A busway — quick, modular protection taps that minimize downtime and field wiring.
• Supports ED, EHD and FDB breakers in the 15–100A range, giving you flexible protection options within a single enclosure family.
• Modular, scalable design — expand protection as your load grows without complex reconfiguration or new panels.
• Compact footprint tailored for spaces where traditional panels don’t fit, simplifying installation in restricted electrical rooms or crowded utility areas.
• Enclosed protection for safety and organization — the enclosure contains breakers and connections, helping keep wiring neat and reducing exposure in busy equipment spaces.

Use cases and who benefits

PINFD is a practical choice for facilities that need flexible protection added to an existing 100A busway. It’s especially well-suited for data centers, manufacturing floors, and commercial/industrial installations where modular expansion, easier maintenance, and faster commissioning matter. If you’re retrofitting a busway or planning a phased upgrade, PINFD lets you deploy additional breaker protection quickly without dismantling your current setup.

How it works

1. Address the 100A Eaton busway with the PINFD enclosure, aligning with the busway’s plug-in interface.
2. Insert compatible ED, EHD, or FDB breakers (15–100A) into the enclosure to establish protected tap points.
3. Secure the enclosure to ensure stable electrical connections and clean, contained wiring within the housing.
4. Commission and test protection as part of your distribution scheme, with the ability to scale by adding additional PINFD modules as needed.

Practical tips

• Verify breaker type and ampere rating (ED, EHD, or FDB; 15–100A) before ordering to ensure seamless compatibility with PINFD.
• Plan for phased protection expansions by leveraging the modular nature of PINFD in your facility’s electrical roadmap.
• Maintain clear labeling for each plug-in enclosure to simplify future maintenance and fault tracing.

Enhance your Eaton 100A busway system with the PINFD Breaker Plug-In Enclosure from AmpState — a focused, scalable solution that brings molded-case protection right to the source, with a clean, plug-in design that keeps your distribution layout efficient and organized.
