Eaton PIGS100 is the dedicated internal ground stab engineered for 100A busway plug-in units. It delivers a reliable ground connection for plug-in outlets and devices, ensuring safe, consistent performance across industrial electrical distributions.

Designed to live inside the plug-in unit, the PIGS100 provides a precise, concealed grounding path that stays protected from debris and incidental contact. This targeted solution minimizes exposure while delivering a dependable ground reference wherever 100A busway plug-in configurations are used.

• Exact fit for 100A busway plug-in units: Eliminates compatibility guesswork and ensures a secure, standardized grounding interface.
• Concealed, internal design: Keeps the ground stab protected inside the unit, reducing wear and exposure without compromising accessibility for maintenance checks.
• Reliable ground path: Establishes a consistent grounding connection for plug-in outlets and devices connected to the 100A busway system.
• Industrial-grade reliability: Built to withstand demanding environments typical of commercial and manufacturing settings, helping to maintain safety and uptime.

Practical use cases

• New installations in facilities that deploy 100A busway plug-in units, where a dependable ground connection is mandatory for safety and equipment protection.
• Repairs or upgrades to existing busway systems that rely on plug-in outlets and devices requiring a stable ground reference.
• Temporary or relocated workspaces within factories or data centers that use modular busway plug-ins and demand robust grounding solutions.

How it works

The PIGS100 integrates directly into the 100A busway plug-in architecture, contacting the busway’s ground plane to form a solid, low-impedance ground path when outlets or devices are connected. This streamlined, internal approach minimizes points of failure and maintains a clean, orderly grounding interface across all plug-in points.

Installation and maintenance guidance

• Ensure the busway system is a 100A configuration compatible with Eaton plug-in units before installation.
• Inspect the plug-in housing and surrounding components for corrosion or damage prior to installing the ground stab.
• Install during a de-energized installation window following site safety protocols, and verify the ground path after seating all plug-in devices.
• Perform periodic inspections as part of routine electrical system maintenance to confirm the ground connection remains uninterrupted and secure.

Who benefits from the Eaton PIGS100

Electrical engineers, facilities managers, and maintenance teams responsible for industrial power distribution will appreciate a purpose-built grounding solution that aligns precisely with 100A busway plug-in units. It simplifies installs, supports compliance with grounding requirements for plug-in devices, and helps minimize downtime by reducing grounding-related issues during operation or relocation of plug-in outlets.

In short, the Eaton PIGS100 ground stab is a focused, reliable choice for anyone operating 100A busway systems who demands a durable, internally mounted grounding solution that keeps plug-in outlets and devices safely bonded to earth.
