Eaton DPU222RGF20 - 60A, 240V, Pullout Switch

The Eaton DPU222RGF20 is a rugged 60A, 240V pullout switch designed to deliver clean, reliable isolation and dependable overcurrent protection in demanding industrial and commercial settings. Built to withstand harsh environments, this compact fusible switch provides a clear, safe disconnect for maintenance and servicing, helping minimize downtime and protect connected equipment.

Key specifications

• Model: DPU222RGF20
• Amperage: 60A
• Voltage: 240V
• Configuration: Pullout fusible switch
• Applications: Motor disconnects, panelboards, and branch circuit protection in compact control environments

Why the DPU222RGF20 stands out

In environments where quick and deliberate isolation matters, the DPU222RGF20 delivers a dependable pullout mechanism that technicians can operate with confidence. The pullout design simplifies maintenance by allowing the fuse element and switching components to be accessed and serviced without removing the entire assembly from the panel. This translates to faster fuse changes, reduced exposure to live circuits, and streamlined control panel upkeep.

With its 60A, 240V rating, this switch is purpose-built for mid-tier motor loads and branch circuits, offering a compact footprint that fits smaller control panels without sacrificing protection or performance. The fusible switch configuration delivers immediate interruption during overcurrent events, safeguarding downstream equipment and wiring from damage while staying compatible with common control panel architectures.

Ideal use cases

• Motor disconnects on small to mid-scale equipment lines where a dedicated, switchable disconnect is required
• Control panels and panelboards needing reliable, maintainable overcurrent protection
• Branch circuits in industrial or commercial facilities where space is limited and serviceability matters
• Localized isolation for preventive maintenance, testing, or equipment swaps without removing the assembly from the enclosure

Practical benefits and how it helps you

• Efficient maintenance: The pullout design exposes the fuse elements and switching contacts, enabling quicker inspections and replacements without dismantling the panel.
• Space-conscious protection: A compact form factor fits tight electrical rooms and small control cabinets while still delivering robust protection.
• Clear, intentional isolation: A dedicated on/off pullout provides a visible, tactile disconnect, reducing the risk of accidental energization during service.
• Reliable overcurrent protection: Fusible switching becomes a safeguard against surges and faults, helping protect motors and wiring from damage during faults.
• Maintenance-friendly lifecycle: Designed for industrial and commercial environments where equipment is subject to regular servicing, providing long-term reliability with straightforward fuse management.

Who this product is ideal for

Electrical engineers, panel builders, and maintenance technicians working in manufacturing floors, process facilities, or commercial mechanical rooms will find the Eaton DPU222RGF20 particularly valuable. It’s suited for systems where a dedicated motor disconnect or branch-circuit protection is needed in a compact chassis, and where serviceability and clear isolation are priorities.

Tips for optimal use

• Match the 60A rating with the connected load to ensure protection without nuisance tripping.
• Maintain a stock of compatible fuses for quick replacement during scheduled maintenance or fault conditions.
• Label the disconnect clearly in the control panel to indicate the purpose (motor disconnect, circuit protection, etc.) and the required safety procedures.
• Regularly inspect the pullout mechanism for smooth operation and confirm that the contacts seat fully when in the ON position.
• Follow local electrical codes and industry standards when integrating the DPU222RGF20 into panelboards and control circuits.

Technical overview at a glance

• Type: Pullout fusible switch
• Load rating: 60A at 240V
• Primary use: Motor disconnects, panelboards, branch circuit protection
• Construction focus: Compact, maintainable design suitable for rugged environments

Choose the Eaton DPU222RGF20 when you need a dependable, serviceable disconnect solution that protects equipment, simplifies maintenance, and fits into space-constrained control panels. Its combination of 60A, 240V capability and a practical pullout mechanism makes it a thoughtful choice for protecting motor loads and branch circuits while keeping downtime to a minimum.
