Eaton / Cutler-Hammer FDPW325BR – 400A, 3-Pole Vertical Bottom Feed Main Fusible Panel-Mount Switch – FDPW Series

The Eaton / Cutler-Hammer FDPW325BR is a rugged, industrial-duty main fusible panel-mount switch designed to deliver dependable load isolation and overcurrent protection in demanding electrical environments. With a 400 A rating and a 3-pole configuration, this unit is purpose-built for three-phase panelboards and switchboards that require a reliable, integrated disconnect solution. The vertical bottom-feed design simplifies wiring layouts and enclosure integration, making it a practical choice for space-constrained installations.

Key specifications at a glance

• Current rating: 400 A
• Configuration: 3-pole (three-phase)
• Mounting style: Panel-mount
• Protection type: Main fusible switch for overcurrent protection
• Feed orientation: Vertical bottom feed
• Series: FDPW Series by Eaton / Cutler-Hammer

Why it matters for your electrical distribution

In industrial settings, a single, reliable main disconnect is essential to safely isolate a system for maintenance and to provide clear protection against overcurrents. The FDPW325BR combines a main fuse with a detection-free disconnect, reducing wiring complexity and simplifying the upgrade or retrofit of switchboards and panelboards. The vertical bottom-feed configuration aligns with common enclosure layouts, helping you achieve tidy, dependable installations without bending or awkward routing of conductors.

Ideal uses and applications

• Main disconnect for switchboards and panelboards in manufacturing facilities, plants, and utility spaces
• Primary protection stage in three-phase electrical distributions requiring robust isolation and quick fault interruption
• Upgrading older equipment where a compact, integrated fusible solution improves safety and maintenance workflow

Practical benefits and how it improves your workflow

• Integrated protection and isolation: By combining a main fuse with a panel-mount disconnect, you gain reliable overcurrent protection and a clear, safe isolation point in one compact device.
• Space-efficient, bottom-feed design: Vertical bottom feeding simplifies wiring paths and enclosure planning, helping you maximize available cabinet space.
• 3-phase readiness: The 3-pole configuration is ideal for modern three-phase power systems, supporting balanced distribution and streamlined maintenance checks.
• Durable for industrial environments: Built to withstand the demands of switchboard and panelboard installations, delivering consistent performance where it counts.

Maintenance and installation tips

Plan for fuse replacement as part of routine maintenance, and keep a compatible fuse inventory on hand to minimize downtime. When wiring, ensure compliant torque on terminals and verify alignment within the enclosing panel to maintain reliable contact and clearance. The vertical bottom-feed orientation should be matched to your enclosure’s cavity design to optimize cable routing and ease of future upgrades.

Equip your electrical distribution with the FDPW325BR to achieve a dependable, code-conscious main disconnect that delivers precise, fail-safe isolation and robust overcurrent protection in a compact, panel-mount form factor.
